AQ1001 - High grade Integrated amplifier (6550 x 4)
Model | AQ1001/A101 |
Output Power | 50W x 2 |
Frequency responsible at 1 W | 15Hz - 23KHz |
Distortion at 1W | < 0.1% |
Distortion at full power | < 3% |
Frequency responsible at full power | 23Hz - 24KHz |
S/N Ratio / Noise level mV | 83 db /1.8mV |
S/N Ratio with A weighting | 95 db (0.7mV) |
Input impedance | 100K |
Output Impedance | 8, 16 ohm |
Input sensitive | 400mV |
Power request | 340W |
Fuse | 5A Slow blow |
Power cord - Detachable /Fixed | Detachable |
Input Sockets | RCA Gold Plate |
Output Termininal | 5 Way Gold Plate Heavy duty |
Chassis Finish | Shinning Steel |
Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
Tube Complement | KT88 x 4, 12AU7 x 4 |
Dimension W x D x H in mm | 395 x 260 x 220 |
Shipping Dimension W x D x H in mm | 470 x 350 x 315 |
Net Weight /Kg | 19Kg |
Shipping Weight /Kg | 21Kg |
