AQ1002
Stereo Push/Pull Power amplifier
| Model | AQ1002 |
| Output Power | 50W x 2 |
| Frequency responsible at 1 W | 10Hz - 30KHz |
| Distortion at 1W | < 0.3% |
| Distortion at full power | < 3% |
| Frequency responsible at full power | 20Hz - 25KHz |
| S/N Ratio / Noise level mV | 82 db /1.6mV |
| S/N Ratio with A weighting | 95 db (0.5mV) |
| Input impedance | 100K |
| Output Impedance | 4,8,16 ohm |
| Input sensitive | 300mV |
| Power request | 340W |
| Fuse | 5A Slow blow |
| Power cord - Detachable /Fixed | Detachable |
| Input Sockets | RCA Gold Plate |
| Output Termininal | Heavy duty gold plate 5 ways speaker post |
| Chassis Finish | Shinning steel |
| Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
| Tube Complement | 6550 x 4, 12AU7 x 4 |
| Dimension W x D x H in mm | 430 x 320 x 240 |
| Shipping Dimension W x D x H in mm | 500 x 400 x 300 |
| Net Weight /Kg | 19Kg |
| Shipping Weight /Kg | 21Kg |
