AQ1008 - 110W
Push/Pull Mono block Power amplifiers -6550 x 4
Model | AQ1008 |
Output Power | 110W |
Frequency responsible at 1 W | 10 Hz - 100Khz |
Distortion at 1W | < 0.1% |
Distortion at full power | < 3% |
Frequency responsible at full power | 18Hz - 28Khz |
S/N Ratio / Noise level mV | 80 db /3mV |
S/N Ratio with A weighting | 97 db (0.4mV) |
Input impedance | 100K |
Output Impedance | 4,8,16 Ohm |
Input sensitive | 1V |
Power request | 335W |
Fuse | 5A Slow blow |
Power cord - Detachable /Fixed | Detachable |
Input Sockets | RCA Gold Plate |
Output Termininal | Heavy duty gold plate 5 ways speaker post |
Chassis Finish | Shinning Steel |
Front Panel Finish | Aluminium with Anodizing , Gold , Silver or Black |
Tube Complement | 6550 x 4,6SN7 x 2 |
Dimension W x D x H in mm | 260 x 395 x 220 |
Shipping Dimension W x D x H in mm | 350 x 470 x 315 |
Net Weight /Kg | 19Kg |
Shipping Weight /Kg | 20Kg |
