AQ2004 - Affordable tube line amplifiers
Model | AQ2004 |
Gain | 3.2 |
Maximum output | 10V |
Frequency responsible at 1V | 10Hz - 100KHz |
Frequency responsible at full power | 10Hz - 50KHz |
Distortion at 1V | < 0.1% |
Distortion at full power | < 0.3% |
S/N Ratio / Noise level mV | 83 db /0.8mV |
S/N Ratio with A weighting | 95 db (0.03mV) |
Input impedance | 100K |
Power request | 10W |
Fuse | 1A Slow blow |
Power cord - Detachable /Fixed | Detachable |
Input Sockets | RCA Gold Plate |
Output Termininal | RCA Gold Plate |
Chassis Finish | Iron with powder paint |
Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
Tube Complement | 12AX7 x 1,12AU7 x 2 |
Dimension W x D x H in mm | 160 x 230 x 160 |
Shipping Dimension W x D x H in mm | 210 x 270 x 195 |
Net Weight /Kg | 2.5Kg |
Shipping Weight /Kg | 3Kg |
