AQ2005 - PCB type high grade line amplifiers
| Model | AQ2005 |
| Gain | 8 |
| Maximum output | 3.2V |
| Frequency responsible at 1V | 10Hz - 100KHz |
| Frequency responsible at full power | 10Hz - 70KHz |
| Distortion at 1V | < 2% |
| Distortion at full power | < 4% |
| S/N Ratio / Noise level mV | 85 db /0.5mV |
| S/N Ratio with A weighting | 92 db (0.03mV) |
| Input impedance | 100K |
| Power request | 40W |
| Fuse | 1A Slow blow |
| Power cord - Detachable /Fixed | Detachable |
| Input Sockets | RCA Gold Plate |
| Output Termininal | RCA Gold Plate |
| Chassis Finish | Iron with powder paaint |
| Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
| Tube Complement | 5AR4 x 1,6BM8 x 1,12AX7 x 2,12AU7 x 2 |
| Dimension W x D x H in mm | 430 x 290 x 218 |
| Shipping Dimension W x D x H in mm | 530 x 390 x 318 |
| Net Weight /Kg | 8.5Kg |
| Shipping Weight /Kg | 9.5Kg |
