MG-Phono
Phono + line pre-amplifiers at unbeatable price
| Model | MG-Phono |
| Phono | กก |
| Gain | 57 db |
| Frequency responsible | 20Hz + 17db 20KHz - 17db (Riaa) |
| Distortion at 1V | < 1% |
| S/N Ratio / Noise level mV | 79 db /3mV |
| S/N Ratio with A weighting | 88 db (1mV) |
| Line | กก |
| Gain | 21 db |
| Maximum output | 12 V |
| Frequency responsible at 1V | 13Hz - 67KHz |
| Frequency responsible at full power | 13Hz - 47KHz |
| Distortion at 1V | < 0.3% |
| Distortion at full power | < 2.8% |
| S/N Ratio / Noise level mV | 94db /0.2mV |
| S/N Ratio with A weightiong | 98db (0.15mV) |
| Input impedance | 100K |
| Output Impedance | กก |
| Power request | 18W |
| Fuse | 1A Slow blow |
| Power cord - Detachable /Fixed | Fixed |
| Input Sockets | RCA Gold Plate |
| Output Termininal | RCA Gold Plate |
| Chassis Finish | Iron with powder paint |
| Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
| Tube Complement | 12AX7 x 2,12AU7 x 2 |
| Dimension W x D x H in mm | 220 x 370 x 110 |
| Shipping Dimension W x D x H in mm | 320 x 470 x 210 |
| Net Weight /Kg | 3.8Kg |
| Shipping Weight /Kg | 4.3Kg |
