MG-SPM805 Mono block single end , Class A2 power amplifier - 50W x 1
| Model | MG-SPM805 |
| Output Power | 50W |
| Frequency responsible at 1 W | 10Hz - 30KHz |
| Frequency responsible at full power | 20Hz - 25KHz |
| Distortion at 1W | < 0.25% |
| Distortion at full power | < 5% |
| S/N Ratio / Noise level mV | 96 db /0.4mV |
| S/N Ratio with A weighting | 104 db (0.04mV) |
| Input impedance | 100K |
| Output Impedance | 4,8,16 Ohm |
| Input sensitive | 2V |
| Power request | 250W |
| Fuse | 5A Slow blow |
| Power cord - Detachable /Fixed | Detachable |
| Input Sockets | RCA Gold Plate |
| Output Termininal | 5 Way Gold Plate Heavy duty |
| Chassis Finish | Iron with powder panit |
| Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
| Tube Complement | 805 x 1,6L6 x 1,12AX7 x 1 |
| Dimension W x D x H in mm | 260 x 430 x 220 |
| Shipping Dimension W x D x H in mm | 350 x 470 x 333 |
| Net Weight /Kg | 21Kg |
| Shipping Weight /Kg | 23Kg |
