AQ1006/211
Single end Mono block Power amplifiers
Model | AQ1006_211 |
Output Power | 15W |
Frequency responsible at 1 W | 10Hz - 30KHz |
Frequency responsible at full power | 15Hz - 25KHz |
Distortion at 1W | < 1% |
Distortion at full power | < 3% |
S/N Ratio / Noise level mV | 80 db /1.2mV |
S/N Ratio with A weighting | 92 db (0.3mV) |
Input impedance | 100K |
Output Impedance | 4, 8, 16 Ohm |
Input sensitive | 1V |
Power request | 200W |
Fuse | 5A Slow blow |
Power cord - Detachable /Fixed | Detachable |
Input Sockets | RCA Gold Plate |
Output Termininal | Heavy duty gold plate 5 ways speaker post |
Chassis Finish | Shinning Steel |
Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
Tube Complement | 211 x 1,6SN7 x 1,6SL7 x 1 |
Dimension W x D x H in mm | 260 x 395 x 220 |
Shipping Dimension W x D x H in mm | 350 x 470 x 315 |
Net Weight /Kg | 18.5Kg |
Shipping Weight /Kg | 20.5Kg |
