MG-PPSL6
Push/pull stereo amplifier 1W x 2
Model | MG-PPSL6 |
Output Power | 18W x 2 |
Frequency responsible at 1 W | 10Hz - 100KHz |
Frequency responsible at full power | 23Hz - 77KHz |
Distortion at 1W | < 0.3% |
Distortion at full power | < 3% |
S/N Ratio / Noise level mV | 85 db /0.8mV |
S/N Ratio with A weighting | 89 db (0.4mV) |
Input impedance | 100K |
Output Impedance | 8 Ohm |
Input sensitive | 350mV |
Power request | 140W |
Fuse | 3A Slow blow |
Power cord - Detachable /Fixed | Detachable |
Input Sockets | RCA Gold Plate |
Output Termininal | 5 Way Gold Plate Heavy duty |
Chassis Finish | Iron with powder paint |
Front Panel Finish | Aluminium /Gold /Silver or Black Anodizing |
Tube Complement | 6L6 x 4,12AU7 x 2,12AX7 x 1 |
Dimension W x D x H in mm | 195 x 230 x 160 |
Shipping Dimension W x D x H in mm | 200 x 270 x 200 |
Net Weight /Kg | 10Kg |
Shipping Weight /Kg | 11Kg |
